Protection
Modbus
Register "Analog Ch Status" Bit Definition
Table 2-35: Register "Analog ch status" bit definition (TRUE=1).
Register "Analog Ch Status" Bit Definition
Bit representation*
(0x0000)
(No bit set)
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
0x0800
0x1000
*
Important:
- Bit representation is in hexadecimal digits.
- Bit representation can be a combination of more than one condition.
Example:
Bit representation of 0x016A is equal to 0x0002 Ch alert +
Refer to Bit Representation of Combined Conditions
2 - 190
Description
Ch not configured.
Ch enabled
Ch alert
Ch startup
Ch danger
Ch danger first out slot
Ch circuit fault.
Note: Ch circuit fault overrides all other status.
For CDE combined measurement: if both corresponding channels X and Y are in ch
circuit faults, the CDE combined measurement will be in ch circuit fault.
For other types of combined measurements: if a corresponding channel X or channel Y is
in ch circuit fault, the combined measurement will be in ch circuit fault.
Ch disarmed
For all types of combined measurements: if a corresponding channel X or channel Y is in
channel disarm, then the combined measurement will be set to channel disarm.
Slot disarmed
For all types of combined measurements: if corresponding channels X and Y are in slot
disarm, then the combined measurement will be set to slot disarm.
Trip multiply
Ch is a part of CDE setup but not used for the moment
Ch danger first out of rack
Ch Gap alert
Ch Gap danger
0x0008 Ch danger +
0x0020 Ch circuit fault +
0x0040 Ch disarmed +
0x0100 Trip multiply
for combined conditions.
