Protection
Protection Part Operation
Table 2-14: Relay module circuit faults – RLM Slave 0 to 7.
Relay Module Circuit Faults – RLM Slave 0 to 7 (Relay Slaves 0 to7)
Bit representation*
(0x0000)
(No bit set)
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000
2 - 44
Condition
CF_STATUS_OK
CF_CONFIG
CF_RS485INT
CF_CFG_MISMATCH
CF_SELFTEST
CF_DOWNLOAD
CF_RELBUS_S1
CF_RELBUS_S2
CF_RELBUS_S3
CF_RELBUS_S4
-
CF_STARTUP
Comments
Normal. No errors.
User configuration dependent:
Check IMx-M configuration settings.
Internal RS485 communication error:
Check modules are firmly positioned.
Master and slave may have different firmware
version in use - check the current firmware version
in use (intd0) on both Master and slave.
Configuration mismatch detected:
See "Protection Configuration
Check for self test errors during startup.
Download ongoing.
PRM 1, relay bus error:
Check configuration.
Check PRM 1 is firmly positioned.
PRM 2, relay bus error:
Check configuration.
Check PRM 2 is firmly positioned.
PRM 3, relay bus error:
Check configuration.
Check PRM 3 is firmly positioned.
PRM 4, relay bus error:
Check configuration.
Check PRM 4 is firmly positioned.
Not used
Indicated during startup phase
