Protection
Protection Part Operation
Table 2-10: Slaves and the corresponding channels.
2
Slaves and Corresponding Channels
Slave
0
1
2
3
4
5
6
7
3
I
mportant:
- Bit representation is in hexadecimal digits.
- Bit representation can be a combination of more than one condition.
Example:
Bit representation of 0x036A is equal to 0x0002 CF_RS485INT +
Refer to Bit Representation of Combined Conditions
Table 2-11: PRM CF Selftest bit definition.
Register "PRM CF - Selftest" Bit Definition**
Bit representation*
(0x0000)
(No bit set)
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
2 - 40
Channel A
Channel 1
Channel 3
Channel 5
Channel 7
Channel 9
Channel 11
Channel 13
Channel 15
0x0008 CF_SELFTEST +
0x0020 CF_AD +
0x0040 CF_CH_A +
0x0100 CF_STARTUP
0x0200 CF_CH_A_CFLATCH
for combined conditions.
Register "PRM CF Selftest" Bit Definition
Description
Not used
Selftest startup
Selftest FW CRC
Selftest configuration CRC
Selftest RAM RO
Selftest CSTACK
Selftest ISTACK
Selftest RAM
Selftest PSM
Channel B
Channel 2
Channel 4
Channel 6
Channel 8
Channel 10
Channel 12
Channel 14
Channel 16
