Protection
Protection Module Configuration with IMx-M Manager
Table 2-17: TCP/IP address/Slot ID when configured by HEX rotary switch.
HEX rotary TCP/IP address/Slot ID
switch (x1)
CMM + PRM Slot
1
0
Software defined
1
01
2
05
3

09

9
33
 A
 37
F
57
Factory default configuration TCP/IP address: 10.0.0.1XY
2 - 102
Figure 2 - 79.
Setting the IP Address by Using Hardware Switches.

It is required to set the first three part of the IP address of IP Settings
manually.

The last part of the IP address will be controlled by the HEX rotary switch
on IMx-M. For example, 10.0.0.1XY, where XY is derived from a combination of
the CMM + PRM slot number and the HEX rotary switch position (see the table
below).
CMM + PRM Slot
2
Software defined
02
06
10

34
 38
58

These last two digits will also form the slot ID.

The HEX rotary switch has to be set manually.

The HEX rotary switch for IMx-M is located inside, back of the right-most
panel (looking at the rack from the front panel). In order to access it, first turn
off the power, then take the right-most panel out.

If the right-most slot has been mounted with a CMM + PRM pair, the CMM
must be dismounted first before the PRM due to the physical reason.
Otherwise, PRM can be damaged seriously. However, when mounting the
CMM + PRM Slot CMM + PRM Slot
3 4
Software defined Software defined
03 04
07 08
11 12
 
35 36
 39  40
59
60
