Protection

IMx-M Manager

IMx-M Manager

Installation of IMx-M Manager

The installation of the IMx-M Manager application tool is done via @ptitude Observer
installation, Custom Setup option where IMx-M Manager can be selected and installed.
For detailed information refer to @ptitude Observer Installation Manual.

Introduction to IMx-M Manager

IMx-M Manager is a tool which enables the user to configure the condition monitoring
modules, protection modules and relay modules within an IMx-M rack.
For the physical installation, each protection module must be paired with a condition
monitoring module to form a CMM + PRM pair.
In the IMx-M Manager a slot consists of the configurations for the CMM + PRM pair.
From the IMx-M Manager's configuration point of view, configuring a "slot" means
configuring the CMM network settings, a PRM and an associated RLM.
The following are performed slot wise only:

Configuration of channels and relays

Circuit fault status report

Activation of slot disarm of protection module and relay module

Configuration of network connection
