SKF Multilog On-Line System IMx-M
User Manual
Figure 2 - 121.
Entering the Slave Channel Sensor Values.
Once the basic sensor parameters have been entered, we then need to set the
Target Position Direction to "Inactive / Counter (Towards Probe)". See figure
below:
Protection Module Configuration with IMx-M Manager
Protection
2 - 155
