Protection
Modbus
Exported (Read) Modbus Registers
Register
IMx-M item
number (1)
849
Analog Ch 1
Alert/Danger
Scale Factor
 
864
Analog Ch 16
Alert/Danger
Scale Factor
897
Analog Ch 1
Trip Multiply
Factor
 
912
Analog Ch 16
Trip Multiply
Factor
945
Protection
Module (3)
946
FW Version (3)
947
CFG (3)
948
949
950
951
IMx-M
Manager (3)
952
CFG CRC32 (3)
953
954
1025
Dig Ch 1 Alert
Low
 
Dig Ch 8 Alert
1032
Low
2 - 184
Function Data type
See table Analog Ch 16-bit mask
Alert/Danger
Threshold Scaling
Factors
See table Analog Ch 16-bit mask
Trip Multiply Factor
Definition
Serial number MSB Unsigned 16 bits MSB
Serial number LSB Unsigned 16 bits LSB
FW Version Unsigned 16 bits
Configuration Label Two 8-bit unsigned
MSB char MSB
Configuration Label Two 8-bit unsigned
LSB char LSB
Configuration version Two 8-bit unsigned
char
IMx-M Manager Two 8-bit unsigned
version MSB char MSB
IMx-M Manager Two 8-bit unsigned
version LSB char LSB
CFG CRC32 MSB Unsigned 16 bits MSB
CFG CRC32 LSB
Unsigned 16 bits LSB
Digital Ch 1 Alert Low
Threshold

Unsigned 16 bits
Digital Ch 8 Alert Low
Threshold
Min and Max
-
-
Unsigned 32 bits
(0x00000000 to
0xFFFFFFFF)
0x0000 to 0xFFFF
(0 to 65 535)
Four ASCII bytes
(characters)
E.g. ABCD
Two ASCII bytes
(characters)
E.g. AB
Four ASCII bytes
(characters)
E.g. ABCD
Unsigned 32 bits
(0x00000000 to
0xFFFFFFFF)
0 to 65 535
