Protection Part Diagnostic Commands

Protection Part Diagnostic Commands
Diagnostic commands are used to obtain information on various conditions of the IMx-
M system.
Diagnostic information will be available for the protection module to where the mini
USB cable is connected. Therefore, connect a mini USB cable to the protection module
for which various conditions will be checked.
Diagnostic commands can be performed by using the application tool IMx-M Manager
provided by @ptitude Observer DVD.
Set the Serial Communication to
commands manually on the Command area.
Important - It is strongly recommended to use the diagnostic interface in
disarmed mode only.
Table 4-13: Protection part diagnostic commands.
Command Description
adc1 Status of internal power and the PRM internal temperature
Current circuit fault status (it is recommended to use "Send CF Command" via IMx-M
cf
Manager's
cfguser User configuration events by entering 8-character user name after the command
ch Analog channel status
Current user configuration (it is recommended to use "Get PRM Config from device" via
dumpcfg
IMx-M Manager's
Current FW versions in use by the PRM and RLM. Use this command to ensure all
intd0
slaves are running proper FW.
mb10 Modbus 1 (RS 485 connection L1) statistics
mb20 Modbus 2 (RS 485 connection L2) statistics
reboot Reboot command
FW version in use by the PRM and RLM. This shall only be used when the system is
sver
disarmed.
ver FW version information
4 - 36
PRM Serial Interface
PRM Serial Commands)
PRM Serial Commands)
and enter the following
SKF Multilog On-Line System IMx-M
User Manual
