Condition Monitoring Part Diagnostic Commands

Condition monitoring part diagnostic commands are available for the condition
monitoring module to where USB cable is connected. Therefore, connect a USB cable to
the condition monitoring module for which various conditions will be checked. The
port is located on the front of condition monitoring module.
Diagnostic commands can be performed by using the application tool IMx-M Manager
provided by @ptitude Observer DVD.
Set the Serial Communication to
commands manually on the Command area.
The following diagnostic commands are specific for IMx-M only.
Table 4-14: CMM part diagnostic commands.
Command Description
prot Current status of internal CMM and protection part communication
GET_EVENT Event log of protection part. Refer to

Network Related Condition Codes

Via a condition monitoring module USB port, status codes are presented regarding to
the current network (Ethernet) status of the the condition monitoring module to which
the USB is connected.
The most common status codes are described below.
Table 4-15: Network related condition codes.
Code
t_connect returned IMx has no connection to Ethernet
error 2 or no response from server.
t_connect returned Ethernet link exists but no
error 7 connection to Monitor application.
t_connect returned Ethernet connection reset.
error 8
t_connect returned TCP/IP stack ran out memory.
error 18
t_connect returned IMx is set to "Obtain IP address
error 33 automatically" from DHCP server
but DHCP server is not responding.
SKF Multilog On-Line System IMx-M
User Manual
Condition Monitoring Part Diagnostic Commands
CMM Serial Interface
Event Log
Description
and enter the following
for detailed information on output.
Possible Cause
Ethernet cable not connected / no link.
Server computer is offline.
Communication port (default 1000) from IMx to
Monitor blocked by firewall.
Monitor application not started.
Network configuration is not set up properly.
Communication port (default 1000) from IMx to
Monitor blocked by firewall.
Computer's firewall is ON.
IMx IP address is banned.
Data removal and network packet handling at the
same time. Removing data causes the system to use
memory needed for network packet.
DHCP server is down or does not exist.
Hardware
USB
