Program Number—Set the slide button to the on position to enable, then enter or
select the program number. When disabled, the first available program is used.
•
Max Time-Shift—Sets the size of the internal Time-Shift buffer that may be used to
delay the source.
•
Force 8 Bit Video—Forces the source to be 8 bit instead of 10 bit regardless of orig-
inal source.
•
Freeze on LOS—Causes the source to hold the last good frame if there is a loss of
signal.
•
LOS Video Test Pattern—Select the test pattern to display when there is a LOS.
Note: The LOS Audio Test Signal is not available for Transport Stream sources.
•
Assign Processor—Assign this source and its dependents to a single processor.
When on, all processing is assigned to a single multi-core CPU socket. This prevents
inefficient mapping of processes across CPU sockets during heavy loads, such as
when all four inputs are being processed. Assign processor should be applied only
to SD/HD sources, not 4K.
•
Use Inverse Telecine—Sets the source to be de-interlaced using Inverse Telecine
settings.
•
TS Over RTP—When enabled, wraps the Transport Stream in an RTP packet.
•
TS Over SRT—When enabled, the Transport Stream is sent using the SRT protocol.
•
Stream dump—Available when
tures the Transport Stream source to the location and file you specify, until you turn
this Stream dump option off. Type the path, folder, and file name into the Stream
dump field. The file extension should be .ts. If the folder you specify does not exist,
the new folder and file will be automatically created.
•
Cisco ID3—Enable to allow the SCTE-104 information to be converted to ID3 on
output. This option can also be turned off or on from Live Capture when configur-
ing SDI sources, see Cisco ID3 in the Configuring SDI Source Options topic in the
Lightspeed Live Capture User Guide. Available only in Advanced Mode.
•
Enable Source Filtering—When enabled, you can enter a list of accepted source IP
addresses. To add IP addresses to the list, press the Enter key after entering an IP
address to add a new entry line.
SCTE-35 Information and ID3 Tag Pass Through or Insertion
When a Transport Stream source contains SCTE-35 information or ID3 tags, this data is
passed through to the output. SCTE-35 and ID3 data can also be inserted via the
Sources API.
Note: Lightspeed Live Capture requires that an IP input source is formated using
standard frame sizes and frame rates. See the Technical Specifications in the
Lightspeed Live Capture product sheet
formats.
