234 Appendix B: Containers, Codecs, and Vantage Actions
QuickTime Output
Y Position. The Y position of the top-left of the timecode in the output video frame
(range: 0 - 2160 pixels).
Font Size. Sets the font size of the timecode (range 6 - 120 pixels).
Text Color. Set the text color of the timecode. The default is black. You can enter simple
color names, such as red, green, or white. Or enter a color hexadecimal code such as
#0000DDFF, which is dark blue. The "FF" characters in this example specify the opacity,
and are optional. When these characters are not included the text is completely opaque
(no transparency). The pound sign (#) must be included with the hexadecimal code.
When a color entry is not valid, the black default is used.
Background Color. Set the color of the area behind the timecode. The default is white.
You can enter simple color names, such as red, green, or blue. Or enter a color
hexadecimal code such as #0000DD, which is dark blue. The pound sign (#) must be
included with the hexadecimal code. When a color entry is not valid, the white default
is used.
Timecode Transparency. The opacity of the timecode. 1.00 is fully opaque, or 100%
opacity, 0 is transparent.
Note: The burned-in Timecode will always represent the actual input timecode being
used by the Input Source.

Audio Stream Details

Select the Audio Stream component to display its details on the right.

Codec (PCM)

Codec. Specifies PCM as the codec to use to encode audio tracks. No other codecs are
provided.

Channel Configuration

Specifies the number and layout of the audio channels:
- Mono
- Stereo
- 4 Channels
- 6 Channels
- 8 Channels
- 10 Channels
- 12 Channels
- 14 Channels
