Trigger Type

Name—Shows the source name.
Thumbnail—Displays a still image of the channel input, updating about once every 3-
5 seconds (depending on server usage load).
Timecode—Displays the current channel timecode.
Gang Recording—Toggles gang recording for the channel. Yellow indicates ON,
and gray is OFF. Channels configured with a Trigger type of Manual, Recurring
Segment, or Web Service (when Manual Override is enabled) can be added to a record
gang.
Current State—Indicates the current channel recording state by color and message:
•
Green—Indicates the channel is ready to record, with a message of Ready (Manual,
Recurring Segment, and DAI), Listening... (Web Service), or Awaiting... (Schedule).
•
Yellow—In a transition state and preparing to record or stop.
•
Red—Recording is occurring. The elapsed duration of the recording is displayed. A
blue progress bar indicates the current recording progress.
Channel Options—Opens the Channel Options menu. See
are queued to start. Click to open the Recordings dialog, which displays information
about the current, queued, and previous recordings. See
Information.
Record/Stop—Click Record to immediately start recording for the channel. When
recording, click Stop to end recording.
Record Options—Click Record Options to open the Record options dialog for the
channel. See
Lightspeed Live Capture User Guide
Queued Job Information—The number displayed indicates how many jobs
Configuring the Custom Ganged Recording
Using the Live Capture Web Application
Live Capture Controls and Operation Status
Channel Options.
Channel Recording
Defaults.
149
