SDI Input Cards

The standard (or optional HEVC; supported by Live Stream only) SDI input card is
installed in the Lightspeed Live server's lower right PCI card slot and provides four SD/
HD/3G-SDI serial digital (SDI) inputs allowing for 4 independent SD/HD/3G SDI signals
or 1 UHD/4K signal. Additionally, one input is provided for an analog Longitudinal
Timecode (LTC) for use across all SDI input signals (see
For the standard card each input consists of a mini-BNC connector and can be converted
to standard BNC with the included mini-standard BNC converter cables. For 4K and Ultra
HD, four BNC connectors provide one 4K or Ultra HD input. The 4K/UHD signal should be
connected to all four BNC inputs. All other resolutions use one BNC per input.
Note: Live Capture 2SI UHD/4K supports 3G Levels A and B as defined in
002. Live Capture SD/HD supports 3G Level A. (Level A consists of an uncompressed video
stream in a serial digital interface at 3 Gbit/s.)
Input Reference
•
•

SDI Card Input Formats

4K
4096 x 2160p
Ultra HD
3840 x 2160p
3840 x 2160PsF
HD
1080i
1080PsF
1080p
720p
SD
625i - PAL
525i - NTSC
Audio
16-Channel 24-bit Little Endian SDI embedded, 48 kHz synchronous
Notes: All 16 channels of audio for UHD/4K are provided on SDI Input #1.
Sources in the YCbCr 444 or RGB 444 color space are not supported. Only the YUV 422
color space is supported.
SD/HD—Reference is derived from an internal free-run clock on each 3G-SDI input.
UHD/4K—Reference is derived from an internal free-run clock on each 3G-SDI input.
23.98
x
23.98
x
23.98
x
x
23.98
24 25 29.97
x x x
24 25 29.97
x x x
x x
24 25 29.97
x x
x x x
x x x
24 25 29.97
x
x
Data and Signal Connections).
EBU Technical Report
30 50 59.94
x x x
30 50 59.94
x x x
30 50 59.94
x
x
x x x
x x
30 50 59.94
