RS-422 Interface Kit Assembly and Installation
4. To prepare the tray mounting
5. Install the Rack Mount Tray
6. To attach the USB cable to the
7. Insert the USB cable into the top
location, place the four G-Type
Cage Nuts onto holes of an
open rack space that is close
to the Lightspeed Live Server.
with the 10-32 rack screws and
washers into the G-Type Cage Nuts.
server, loosen the retaining-arm
screw of the USB Cable Retainer and
slide the arm away from the rear of
the Lightspeed Live server.
port of the server.
