266 Appendix B: Containers, Codecs, and Vantage Actions
MPEG2-TS Output
Note: The burned-in timecode always represents the actual input timecode being
used by the Input Source.
X|Y Position. Specifies (in pixels from the upper left corner origin) the line upon which
to place the timecode text on the video frame.
Font Size. Specifies the font size, in pixels.
Text Color. Specifies the color of the text. Enter a color name (white, red, green, etc.) or
an #RGBA code (for example, #0000DD). The alpha channel is optional.
Background Color. Specifies the color of the area behind the text. Enter a color name
(white, red, green, etc.) or an #RGBA code (for example, #0000DD). The alpha channel is
optional.
Timecode Transparency. Specifies the opacity of the timecode text as a real number.
Zero is fully transparent, and 1.00 (100%) is fully opaque.

Audio Stream Details

Select the Audio Stream component to display its details on the right.

Codec

Specifies that the audio is encoded using the PCM codec. No other codecs are available.

General

Channel Configuration. Specifies the number and layout of the audio channels.
NOTE: 32 channels are not supported from SDI sources.
Label Channel Pairs Left/Right. When checked, forces the first channel pair to be
labeled Left and Right, unless Force One Track Per Channel is selected, in which case
this setting is ignored.
Bit Depth. Specifies the audio bit depth.
Force One Track Per Channel. When checked, the codec creates multiple mono tracks
instead of a single multi-channel track.

Channel Map

Output Channel (1... 32). When checked, enables re-mapping of the incoming source
audio channels to the captured file output channels. Channels are numbered from 1 to
32. Specify the number of the audio input channel to use for each output channel.
