128 Creating Capture & Tape Action Workflows
Creating and Activating the Tape Action Workflow
Output Location. Click Output Location and select from these choices:
- Vantage Store: Write the output to a Live Store. Select any available Live Store from the
drop down list.
- Path: Write the output to a specific Windows file system server and directory. Manually
enter a Windows share (UNC path) or drive letter (not recommended on Vantage arrays)
or click Browse to navigate and select the location. Or, click the green Browse button
and select a variable which supplies the fully-qualified path.
WARNING: In rare instances two capture processes writing to the same Path location
folder could result in one file overwriting the other. To prevent this it is best to use a unique
folder location for each workflow, or append a Time token set to '
one workflow by using Edit Filename, which will return seconds down to a thousandth of a
second and add this onto the file name.
Edit Filename. Displays the Filename Pattern Editor and specifies the pattern for the
file you are creating. Default: Base Name. Use the menu on the right to select one or
more tokens to insert to create the exact filename pattern you require.
Available tokens:
- Base Name: Select to add the base (clip) name as part of the file name. The Base Name
token is populated with the Clip Name selected in Clip Panel of the Tape Capture user
interface.
- Workflow Name: Select to add the name of the workflow as part of the file name.
- Source Name: Select to add the name of the live source as part of the file name.
- Variable: Select to choose and add a variable to the file name.
- Date: Select to add the date as part of the file name.
- Time: Select to add the time as part of the file name.
The Variable token is replaced by the value it holds when the action executes. The
variable should be set prior to execution of this action. For example, if a Variable token
named ISCI is given the value 12H4JA678, wherever the ISCI variable token appears in
the filename pattern it is replaced with that value.
Select Media Nickname. Specifies the nickname for this media.
Delete. Click the X icon on the right to delete the output from this action.

Settings Panel

Specify settings to use for each output configuration. Binding any of these parameters
to variables will make those parameters configurable from within the Tape Capture
user interface.
Ignore Lost Frames. When checked, lost frames do not cause the capture to stop.
mmm
' to the file name in
