340 Appendix D: Live Capture Classic Web Application
Using the Live Capture Classic Web App

Manual Mode Controls and Indicators

When the Capture action Trigger option is set to Manual mode the Channel Control
dialog provides display of the video source, information about the selected channel,
and provides controls for the operation of the channel. The Primary and Secondary
Outputs are both affected by the controls at the same time. See
more information on setting the Trigger option.
Click on a channel to open its Channel Control dialog.
Video View Panel
Operation Controls
Pending Capture State
Status Bar
Workflow Name
Source Name and Input ID
Elapsed Time of Current

Controls for Manual Mode

The following controls are provided in the Channel Control dialog when the Trigger
mode is set to Manual in the Capture action:
Note: For the Timeline Slider, Status Bar, and Time-Shift buffer to be available and
active, the Time-Shift option must be checked in the Program panel of the Capture
action. See
Recording
Program in the Creating Capture Workflows chapter for more information.
Trigger Settings
Close the Dialog
Audio Level Meters
Timecode
Present Capture
State
Timeline Slider /
Frame Step
Seconds in the
Time-Shift Buffer
Video Information
