- 16 Channels
- 32 channels (currently not supported from SDI sources)
Label Channel Pairs Left/Right. When checked, causes the first channel pair to be
labeled Left and Right, unless Force One Track Per Channel is checked, in which case
this setting is ignored.
Bit Depth. Specifies the desired audio bit depth: 16 | 20 | 24 bit.
Force One Track Per Channel. When checked, creates multiple mono tracks instead of
a single multi-channel track. QuickTime audio channel Assignment metadata is set to
'Mono' .
Channel Map. Allows re-mapping of the incoming source audio channels to the
captured file output channels. Channels are numbered from 1 to 32. Specify the
number of the audio input channel to use for each output channel.

QuickTime 'Open' Output

QuickTime 'Open' is implemented in the Capture action with Capture ComponentPac
7.0.4 or later.
Note: Most Lightspeed Live Capture MXF files containing IMX, XDCAM or AVC-Intra,
and all QuickTime Open files, are created in such a way that they can be opened for
editing/playing (in Adobe Premiere Pro CC, Telestream Switch and other media
applications) while they are still growing during capture. Check with your edit/player
application software documentation for further details on supported formats.
Because of the unique characteristics of QuickTime 'Open' files created by Live Capture,
the duration set in the QuickTime header is hard-coded to the value of the Default
Duration setting during capture. If a capture is stopped prior to the timecode specified
in the Default Duration, the QuickTime 'Open' process updates the captured file's
header with the actual duration of the clip. See
Duration
The QuickTime container conforms to the IEC 14496-14 MP4 File Format standard and
the QuickTime File Format Specification.

QuickTime 'Open' Format Summary

Video

Apple ProRes | Avid DNxHD | Avid DNxHR
Lightspeed Live Capture User Guide
below for important details.
