256 Appendix B: Containers, Codecs, and Vantage Actions

Tape Action Output Containers

Tape Action Output Containers
These output containers are included in the Capture action:
■
■
■
■
■
■
■
■

MXF OP1a Output

The MXF container encodes the media and produces an MXF Operational Pattern 1a
(OP-1a, SMPTE 379M-2004) file with a generic container mapped to Lightspeed Live
Capture's available video essences.
Note: Most Lightspeed Live Tape Capture MXF files containing IMX, XDCAM or AVC-
Intra are created in such a way that they can be opened for editing/playing (in Adobe
Premiere Pro CC, Telestream Switch and other media applications) while they are still
growing during capture. Check with your edit/player application software
documentation for further details on supported formats.
Note: Controls with a green Browse button may be bound to a variable to
dynamically assign their setting or value. The variable must have a value when this
action executes. You can assign the value to the variable in a previous action in the
workflow or use the variable's default value. Click Browse to select the variable or
create a new one.
Select the container to display its settings in the configuration panel on the right.

Generic MXF Format Summary

Video

AVC | Avid DNxHD | DV | DVCProHD | IMX | JPEG2000 Lossless | JPEG2000 Lossy |
Panasonic AVC-Intra | Panasonic AVC-Ultra | Uncompressed |Sony XAVC | Sony XDCAM |
x264

Audio

PCM, 16/20/24-bit, 48Kbps, up to 16 channels
MXF OP1a Output
MPEG2-TS Output
QuickTime Output
TIFO Output
Proxy TIFO Output
Proxy MP4 Output
Proxy MXF RDD 25 Output
Poster Frame
