Label Channel Pairs Left/Right. When checked, forces the first channel pair to be
labeled Left and Right, unless Force One Track Per Channel is selected, in which case
this setting is ignored.
Bit Depth. Specifies the audio bit depth.
Force One Track Per Channel. When checked, the codec creates multiple mono tracks
instead of a single multi-channel track.

Channel Map

Output Channel (1... 32). When checked, enables re-mapping of the incoming source
audio channels to the captured file output channels. Channels are numbered from 1 to
32. Specify the number of the audio input channel to use for each output channel.

Proxy MXF RDD 25 Output

The Proxy MXF RDD 25 container conforms to the RDD 25 MXF file format standard.
Note: RDD 25 proxy files can be opened in Telestream's Switch player, and other
applications, as they are being captured and are growing in size. Requires Switch 4.0 or
later.

Container Settings

The Proxy MXF RDD 25 container wraps the specified media into a MXF file format.
File Extension. Specifies .mxf. No other extensions are available.

Video Stream Details

Select the Video Stream component to display its details on the right.

Codec (AVC)

Codec. Specifies PCM as the codec to use to encode audio tracks. No other codecs are
provided.

AVC

Same as Source
When enabled, the width and height of the source is passed through. Width and Height
parameters set in the action for the AVC codec are ignored.
