Note: Controls with a green Browse button may be bound to a variable to
dynamically assign their setting or value. The variable must have a value when this
action executes. You can assign the value to the variable in a previous action in the
workflow or use the variable's default value. Click Browse to select the variable or
create a new one.
Select the container to display its settings in the configuration panel on the right.
Format Summary
Video
AVC
Audio
PCM
Container
MP4 Config Name. Specifies the custom name of this output configuration. Displayed
as a Configuration Template (along with all other outputs in this action) in the Capture
Web app, so that the operator can select a specific Output configuration for the current
capture session.
Container Settings
File Extension. Specifies the file extension of the generated MP4 file.
Aspect Ratio Mode
Aspect Ratio Mode. Specifies how to set the display or pixel aspect ratio of the output:
When Automatic is selected, the aspect ratio is set automatically, based on the
detected content.
Display Aspect Ratio. When Display Aspect Ratio is selected, specifies 4:3 | 16:9.
Pixel Aspect Ratio. When checked, specifies the selected pixel aspect ratio.
Video Stream Details
Select the Video Stream component to display its details on the right.
Codec (AVC)
Codec. Specifies AVC. No other codecs provided.
Lightspeed Live Capture User Guide
Appendix B: Containers, Codecs, and Vantage Actions
287
Proxy MP4 Output
