Time Code Burn-in Filter

Select to have the media timecode burned into the output video.
You can set the following options:
X Position—The X position of the top-left of the timecode in the output video frame.
The range is from 0 to 4096 pixels.
Y Position—The Y position of the top-left of the timecode in the output video frame.
The range is from 0 to 2160 pixels.
Font Size—Sets the font size of the timecode. The range is from 6 to 120 pixels.
Text Color—Set the text color of the timecode. The default is black. You can enter
simple color names, such as red, green, or white. Or enter a color hexadecimal code
such as #0000DDFF, which is dark blue. The "FF" characters in this example specify the
opacity, and are optional. When these characters are not included the text is
completely opaque (no transparency). The pound sign (#) must be included with the
hexadecimal code. When a color entry is not valid, the black default is used.
Background Color—Set the color of the area behind the timecode. The default is white.
You can enter simple color names, such as red, green, or blue, or enter a color hexadecimal
code such as #0000DD, which is dark blue. The pound sign (#) must be included with the
hexadecimal code. When a color entry is not valid, the white default is used.
Timecode Transparency—The opacity of the timecode. 1.00 is fully opaque, or 100%
opacity, 0 is transparent.
Note: The burned-in Timecode will always represent the actual input timecode being
used by the Input Source.
