146 Using the Live Capture Web Application
Live Capture Controls and Operation Status

Configuring the Custom Ganged Recording Defaults

When you select Record Ganged - Custom, a dialog opens to select which channels to
include in the record operation and the settings to use for all channels.
Channel Name(s)—For each Manual Trigger or Recurring Segment Trigger, displays
the name of the workflow channel and the name of the input for that channel. The
channels that are checked will be included in the record operation.
Primary Output Location—Select a Vantage folder address book entry for the
destination of the primary output, or use the default location specified in the Capture
action workflow.
Secondary Output Location—Select a Vantage folder address book entry for the
destination of the secondary output, or use the default location specified in the
Capture action workflow. The secondary output must be enabled in the Capture action
for each channel included in the record operation for this to be active.
Base Name—Type a name for the Base Name token. This name appears in the job
name and is only used in the output media filename pattern when the Base Name
token is added in the Filename Pattern Editor in the Capture action for this channel. The
Base Name entered will be applied to all channels selected for recording. To add the
Base Name token, see Primary and Secondary Outputs.
Lightspeed Live Capture User Guide
