Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 94

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
4 Data Modules and Asynchronous Data Units
Connect Data Modules
1. Calculate an option-selection value using
default settings of the 8400B data
for all options that you wish to disable.
For example, if you turned off With Telephone, US Companding, Disable
Data Metering Feature, the selection code would be:
1 + 2 + 16 = 19
2. Check the current data-module setting by entering ATS24?.
3. If the current value does not match the selection value you calculated,
enter ATS24= nnn , where nnn is the selection value you calculated.
Configuring the ExpressRoute 1000 Data Module
You can substitute an ExpressRoute 1000 data module for the 8400B data
module. Both DCP and ISDN-BRI connections are possible.
typical connections.
!
CAUTION:
In DC-powered cabinet installations, a 105C Isolator adapter is required
when connecting equipment to a data module.
Figure 12, ''Codes for disabling
module''. Add up the disabling codes
Figure 18
Issue 1
April 2000
72
shows
