3 Voice and Data Terminals and Extenders

DEFINITY DCP Extender, Rack Mount

DEFINITY DCP Extender, Rack Mount
Figure 9 shows a typical rack mount (multi-mount) DCP extender. Connections
from either a digital line 17-port 2-wire DCP circuit pack or a digital line 24-port 2-
wire DCP circuit pack, are made through two DCP extender devices. The stand
alone extender installs at the work location. To install the stand-alone unit, refer to
the installation instructions in
this chapter. Refer to
Pinout''. The DEFINITY Extender Switch Module System Administrator's Guide
contains additional information.
1. Front of rack mount assembly
2. First circuit pack in slot 1 ("A")
3. Slot 12 ("L")
Figure 9. Typical DEFINITY DCP Extender Connections
''DEFINITY DCP Extender, Stand Alone''
Appendix A, Table 35,
h2dferm PDH 100796
4. Rear of rack mount assembly
5. 25-pair connector to the MDF and the digital
line circuit packs
6. Power connector
''DCP Extender 25-Pair Cable
Issue 1
April 2000
