4 Data Modules and Asynchronous Data Units
Connect Data Modules
Setting interface options on 7400A DCE
1. To access the menus, press the NEXT/NO button.
2. When the SET OPTIONS? prompt appears on the LCD. Press the NEXT/
NO button.
3. The VIEW OPTIONS? prompt appears. Press the NEXT/NO button.
You will return to the options menus in a minute. But first you must select a
command interface for the data module.
4. The SET INTERFACE? prompt appears. Press the ENTER/YES button.
A series of INT = InterfaceType ? prompts appears.
0 0 — 0 0
Push the button indicated by the arrow ( )
SET OPTIONS?
Push the button indicated by the arrow ( )
VIEW OPTIONS?
Push the button indicated by the arrow ( )
SET INTERFACE?
Push the button indicated by the arrow ( )
0 — —
DATA
DATA
DATA
DATA
April 2000
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
