Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 220

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
A Connector and Cable Pinout Charts
Table 32. DS1 Interface cable H600-348
50-Pin
Pin Color
22 O-R
48 R-G
23 G-R
Table 33. DS1 Interface Cable H600-307
50-Pin
Pin Color
02 W-BL
03 BL-W
47 W-G
22 G-W
48 W-BR
23 BR-W
49 W-SL
24 SL-W
All other pins empty.
Table 34. TN2185B ISDN-BRI — 4-Wire S Interface Pinout
Port Signal Cross-Connect Pin
1 TXT.1 1
TXR.1 2
PXT.1 3
PXR.1 4
15-Pin
Designation Pin
LI 03
LO 09
LO (High) 01
15-Pin
Designation Pin
LI (High) 11
LI 03
LO 09
LO (High) 01
LOOP2 07
LOOP1 05
Color
W-BL
BL-W
W-O
O-W
Color Designation
O-R LI
R-G LO
G-R LO (High)
Continued on next page
Color Designation
W-G LI (High)
G-W LI
W-BR LO
BR LO (High)
W-SL LOOP2
SL-W LOOP1
Ampheno
l Pin Backplane Pin
27 102
01 002
27 103
02 003
Continued on next page
Issue 1
April 2000
198
