4 Data Modules and Asynchronous Data Units
Sett Hardware Options
4. Set the switches for the combination of options that you need to enable,
using the chart below as a guide.
No telephone attached, data metering OFF, busyout on local loop OFF
(factory default settings)
O
N 1
DOWN
Telephone attached, data metering OFF, busyout on local loop OFF
O
N 1
UP
No telephone attached, data metering ON, busyout on local loop OFF
O
N 1
DOWN
No telephone attached, data metering OFF, busyout on local loop ON
O
N 1
DOWN
No telephone attached, data metering ON, busyout on local loop ON
O
N 1
DOWN
2 3 4
DOWN DOWN DOWN
2 3 4
DOWN DOWN DOWN
2 3 4
DOWN DOWN DOWN
2 3 4
DOWN DOWN DOWN
2 3 4
DOWN DOWN DOWN
5 6 7
DOWN DOWN DOWN
5 6 7
DOWN DOWN DOWN
5 6 7
UP
DOWN DOWN
5 6 7
DOWN DOWN DOWN
5 6 7
UP
DOWN DOWN
Issue 1
April 2000
31
8 9
DOWN DOWN
8 9
DOWN DOWN
8 9
DOWN DOWN
8 9
UP
DOWN
8 9
UP
DOWN
