DEFINITY
Release 5
8410 Voice Terminal
Quick Reference
555-230-764
Comcode 107672974
Refer to the procedures on this card to use the
features on your 8410 voice terminal. The features
here are listed in alphabetical order. In the spaces
provided, write the feature access codes for your
system. For more information about any of these
features, see your system manager or refer to the
DEFINITY
8410 Voice Terminal User's Guide , 555-230-763.
USING THE SOFTKEYS
If your 8410 has a display, you may be able to access
up to 12 features with the softkeys. You can activate
available softkey features by pressing
the softkey below the feature abbreviation. If the
feature you want to use is not on the bottom line of the
display, press
feature you wish to access. When the feature is active,
an arrow appears above the feature. (However, if the
feature requires you to dial a telephone number or
extension, such as Call Forwarding, you will
temporarily see the digits you are dialing, rather than
the arrow, above the feature name.)
ABBREVIATED DIALING (AD)
To program/reprogram an AD button
1 Pick up handset.
NOTE: For speakerphone users, press a call
appearance button or press
2 Press softkey below Prog (for display users)
or Press
or Dial AD Program access code _________.
3 Press AD button to be programmed.
Enterprise Communications Server (ECS)
®
Enterprise Server (ECS), Release 5
Next
Program
or
Prev
Speaker
1
and then
Menu
until you see the
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voice Terminal 8410 and is the answer not in the manual?

Questions and answers

Related Manuals for Lucent Technologies Voice Terminal 8410

Summary of Contents for Lucent Technologies Voice Terminal 8410

  • Page 1 ® DEFINITY Enterprise Communications Server (ECS) Release 5 8410 Voice Terminal Quick Reference 555-230-764 Comcode 107672974 Refer to the procedures on this card to use the features on your 8410 voice terminal. The features here are listed in alphabetical order. In the spaces provided, write the feature access codes for your system.
  • Page 2 4 Dial outside number, extension, or feature access code you want to store (up to 24 digits). 5 Press 6 Repeat Steps 3 through 5 to program additional buttons. 7 Hang up. To place an AD call 1 Pick up handset or press 2 Press selected AD button.

  • Page 3: Automatic Callback

    AUTOMATIC CALLBACK AUTOMATIC CALLBACK AAUTOMATIUTOMATIC CALLBACK To automatically place another call to an extension that was busy or did not answer 1 During call attempt, press softkey below AutCB (for display users) or Press AutoCallBk 2 Hang up. You hear a 3-burst priority ring when both you and the called extension are idle.

  • Page 4: Call Forwarding All Calls

    CALL FORWARDING ALL CALLS To temporarily redirect all calls to an extension or outside number 1 Press softkey below CFrwd (for display users) or Press Call Fwd or Dial Call Forward access code _______. 2 Dial extension or number where calls will be sent. 3 Hang up.
  • Page 5 CONFERENCE To add another party to a call (for a total of up to 6 parties) 1 Press Conf 2 Dial number of new party and wait for answer. 3 Press Conf 4 Repeat Steps 1 through 3 for additional conference connections.

  • Page 6: Last Number Dialed

    HOLD To put a call on hold 1 Press Hold To answer a new call while active on another 1 Press Hold 2 Press call appearance of incoming call. To return to held call 1 Press call appearance of held call. LAST NUMBER DIALED To automatically redial the last number you dialed 1 Press softkey below Last (for display users)

  • Page 7: Reset Speakerphone

    RESET SPEAKERPHONE NOTE: You can use this feature only if the Reset Spkr label appears under the To adjust the speakerphone to the surrounding room acoustics 1 While on-hook, press Speaker You hear a series of tones. SELECT RING (and RINGER VOLUME) To select a personalized ring 1 If your 8410 has a then press...

  • Page 8: Send All Calls

    SEND ALL CALLS To send all calls (except priority calls) to coverage 1 While on-hook, press softkey below SAC (for display users) or Press Send Calls or Dial Send All Calls access code _______. To cancel Send All Calls 1 While on-hook, press softkey below SAC (for display users) or Press Send Calls...
  • Page 9 To end a speakerphone call 1 Press Speaker NOTE: With a DEFINITY G3V3 or later, if the person you are talking with hangs up first, the call will be disconnected. If you press tone. STORED NUMBER (display feature) To see number stored on an AD button 1 Press the softkey below View (for display users) or Press Stored...
  • Page 10 2 Dial number where call is to be transferred. 3 Press Transfer 4 Hang up. Prepared by BCS Product Documentation Development Middletown, NJ 07748-9972 and the softkey Menu and the softkey Menu again. again. Issue 2, February 1997 Copyright © 1997 Lucent Technologies Printed in USA...
