4 Data Modules and Asynchronous Data Units
Connect Data Modules
3. When the VIEW OPTIONS? prompt appears on the LCD, press the NEXT/
NO button.
4. When the TEST - RESET? prompt appears on the LCD, press the
ENTER/YES button.
5. When the DATA LOOPBACK? prompt appears on the LCD, press the
NEXT/NO button.
6. When the SELF-TEST? prompt appears on the LCD, press the NEXT/NO
button.
7. When the LOCAL LOOPBACK? prompt appears on the LCD, press the
NEXT/NO button.
VIEW OPTIONS?
Push the button indicated by the arrow ( )
TEST - RESET?
Push the button indicated by the arrow ( )
DATA LOOPBACK?
Push the button indicated by the arrow ( )
SELF - TEST?
Push the button indicated by the arrow ( )
LOCAL LOOPBACK?
Push the button indicated by the arrow ( )
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
DATA
