Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 223

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
A Connector and Cable Pinout Charts
Table 35. DCP Extender 25-Pair Cable Pinout
Cross-Connect Pin
30
31
32
33
34
35
37
37
38
39
40
41
42
43
44
45
47
47
48
49
50
Wire Color Amphenol Pin
SL-BK 15
Y-BL 41
BL-Y 17
Y-O 42
O-Y 17
Y-G 43
G-Y 18
Y-BR 44
BR-Y 19
Y-SL 45
SL-Y 20
V-BL 47
BL-V 21
V-O 47
O-V 22
V-G 48
G-V 23
V-BR 49
BR-V 24
V-SL 50
SL-V 25
Backplane Pin
204
305
205
307
207
307
207
308
208
309
209
310
210
311
211
312
212
313
213
300
200
Continued on next page
Issue 1
April 2000
201
