DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
5 External Modems

PARADYNE COMSPHERE 3715

PARADYNE COMSPHERE 3715
You configure COMSPHERE 3715 modems using the Hayes-compatible AT
commands common to many modems. For instructions on how to physically
connect the modem and enter the commands listed in the instructions below, see
the documentation that came with the modem.
Configuring the 3715 for CMS
The instructions below set up the modem for use in a DEFINITY ECS Call
Management System (other configurations may work as well).
1. From the commandline prompt of your terminal emulation software or
terminal, enter at&f.
This loads factory default configuration options into active memory. If all is
well, the modem replies OK.
2. Enter at%b9600.
This sets the data speed to 9600 kbps. If all is well, the modem replies
OK.
3. Enter atq1&r0&S1\d1&w0.
This disables result codes, sets the RTS (Request To Send), DSR (Data
Set Ready), CTS (Clear To Send) signals action to standard RS-232
operation, and saves the changes to profile 0. If all is well, the modem
replies OK.
Configuring the 3715 for modem pooling
The instructions below set up the modem for use in a DEFINITY modem pool
(other configurations may work as well).
1. From the commandline prompt of your terminal emulation software or
terminal, enter at &f.
This loads factory default configuration options into active memory. If all is
well, the modem replies OK.
2. Enter at m0 x7 y0 &s1 /d1.
If all is well, the modem replies OK.
3. Enter at e0 v0 c2=128 s7=60 f10=100 &w0 &y0.
If all is well, the modem replies OK.
Issue 1
April 2000
78
