Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 208

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
18 Multimedia Communications Products: MMCX, MMCH, ESM
Multimedia Call Handling (MMCH)
Zydacron Configuration
Table 30. Minimum System Requirements
Version:
Minimum Processor Speed:
Disk Space:
Memory:
ISA Expansion Slots (17-bit):
Monitor:
Operating System:
These endpoints do not need any special configuration settings. The standard
configuration for a DEFINITY ECS is as follows. Use the documentation that
accompanies the Zydacron equipment for more details.
1. Open Windows and load the software application.
2. Select Full Installation.
3. Click on OK for the default location of the application directory
(c:\ZYDAPP2).
4. Select Yes to reset the video drivers (if desired).
5. View or close the READZA2.txt file as desired.
6. When the Collaboration Software dialog box opens, select Yes if another
vendor's video conferencing application is being loaded. Select No if only
Zydacron software is being loaded.
7. The software continues to load automatically. When finished, the
application icons appear in the program group.
How to Place a Zydacron Video Call
1. Turn on the video camera. Be sure the green LED is on.
2. Double click on the Zydacron icon to start the program. The program may
take about 30 seconds to open.
3. Two local video windows should appear.
4. Click the Dial icon from the Main toolbar.
5. Use the keypad or the computer keyboard to enter the telephone number
of the test endpoint or telephone.
6. To initiate the call, click on the CALL button. The Incoming Call screen
appears on the test endpoint (or the test telephone rings).
Z250 v. 1.0 or ZydApp2 v. 1.3
487/33 MHz, DX2/77
5 MB
4 MB RAM, 8 MB recommended
1 slot
VGA, SVGA
™
Windows 3.1x or Windows
Issue 1
April 2000
186
™
95
