2 Auxiliary Power Supplies
1145B Power Supply
6
1. Wall mounting plate
2. Optional battery (1149B shown)
3. 1146 power distribution unit
4. 1145B power unit
Figure 3. 1145B/1146 Mounting Arrangement
5. Write the Unit Number and connectivity information on the front label, next
to the LEDs.
1149 Battery
On Battery Reserve
1145 Power Unit
Charging Battery
Output Power On
4
5. Power cable
6. Unswitched outlet (120 VAC, 20 A or 230
VAC, 15 A)
7. Battery backup switch setting
2
5
pcdf1145 KLC 030100
