DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
18 Multimedia Communications Products: MMCX, MMCH, ESM
Multimedia Call Handling (MMCH)
These endpoints do not need any special configuration settings. The standard
PictureTel configuration for a DEFINITY ECS is as follows.
1. Load the LiveShare Plus software first.
2. Enter the user name and company name. Use default values for
subsequent prompts.
3. Enter a site name.
4. Select Restart Windows and FINISH.
5. Load the Live 50 VAFC drivers.
6. Load the Picture Tel Live 50 software.
7. Open the PictureTel Live program group from the Windows
Manager screen.
8. Double click on the PictureTel Live Configure icon.
9. At the Welcome screen, click on continue.
10. Go to the registration confirmation screen and click on continue.
11. Enter the Network Interface Settings. Be sure that "ISDN" has an "x" in
the box. Click on continue.
12. At the ISDN Parameters screen, set the signaling protocol to USA
Canada: 5ESS Custom Point-to-Point. Click on continue.
13. At the Hardware Settings screen, set the following: Interrupt (IRQ) to 11,
Base I/O Port=280, and Base Memory=D000. Under the Video Input
section, select the NTSC circle. Click on continue.
14. At the Audio Device screen, enter the necessary information.
15. At the Node Name screen, enter a name for the PC using the application
software package.
16. At the Modify config.sys screen, click the SAVE button.
17. The remainder of the software loads automatically.
18. When the load is finished, reboot the PC.
19. Open the PictureTel Live program group from the Windows
Manager screen.
20. Double click on the PictureTel Live icon. The program takes about 1
minute to open.
How to Place a PictureTel Video Call
1. Turn on the video camera. Be sure the green LED is on.
NOTE:
A problem may be encountered when trying to open the PictureTel
application software. If the application seems to freeze during
initialization (no response for several minutes) then there may be a
