4 Data Modules and Asynchronous Data Units
Connect Data Modules
You return HOME.
POWER
TEST
Checking DEFINITY administration on 7400A DCE
Check that the DEFINITY is administered to support the 7400A data module in
the DCE application as follows:
1. If necessary, return to the HOME display on the 7400A by pressing the
NEXT/NO and BACK buttons at the same time.
2. From the HOME display, press NEXT/NO until ANS/ORIG CALL? is
displayed, then press the ENTER/YES button.
3. If you see the message WAITING ... DISCONNECTED, the switch has not
been administered correctly.
4. If you see the message DIAL TONE followed by DISCONNECT CALL?,
the DEFINITY is correctly administered for the 7400A data module. Press
the ENTER/YES button to return to the menu.
The 7400A replies WAITING ... DISCONNECTED and returns to the ANS/
ORIG CALL? menu.
5. Return to the HOME display by pressing the NEXT/NO and BACK buttons
at the same time.
Configuring the 7400A for modem pooling (DTE) applications
From the HOME screen, proceed as follows.
Setting speed options on 7400A DTE
1. To access the menus, press the NEXT/NO button.
D D D R
T S R C T
R R I D S
— — — 0 —
7400A Data Module
C
T T R
S D D
— — —
DATA
April 2000
HOME
NEXT/NO BACK ENTER/YES
Issue 1
47
