DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
17
Paging and Announcement Equipment
ESPA Radio Paging
1
1. DCP telephone
2. 4-pair modular cord
3. PassageWay interface
4. 4-pair modular cord
5. 103A or modular wall jack
Figure 57. Typical ESPA Radio Paging Connections
3
LINE
PHONE
POW ER
2
9
6. To digital line circuit pack RS-
232 connector
7. ESPA radio paging equipment
8. Paging loudspeakers
5
4
7
8
cydf004 RPY 123097
Issue 1
April 2000
171
6
