DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
14

DEFINITY INADS

DEFINITY INADS
The DEFINITY ECS Initialization and Administration System (INADS) provides
analog loopback connections and PARTNER
and maintenance when direct connection to the public network is not possible.
NOTE:
These instructions are for DEFINITY ECS Release 7r or later systems using
the TN1648/B system access/maintenance (SYSAM) circuit pack. ISDN is
required.
Analog Loopback
Analog loopback connects the INADS port to an analog station port. It switches
the call through the AUX connector on the processor carrier of the DEFINITY
ECS, across an analog line circuit pack, and out to the public network. Direct
Inward Dialing (DID) is optional.
Installing INADS Analog Loopback on a
Standard-Reliability System
1. Connect the INADS tip and ring port from the AUX connector to an analog
station port via the MDF. See
2. If you are using power-fail transfer, connect the 808A2 transfer panel
between the INADS connection to the station and the INADS connection to
the loop-start trunk.
14
®
connections for remote alarming
Figure 45. Use wire pair 50 and 25.
Issue 1
April 2000
149
