7 DEFINITY LAN Gateway System

Connecting a PC

4. Perform the cross-connects for the alarm origination connection as
described on the service order. Also see
Table 16. Alarm Origination Pinouts (ALB Y-cable)
Pin Number
27
1
44
19
47
22
Connecting a PC
You need a PC to administer the DEFINITY LAN Gateway system. You must have
a local administration PC and a local maintenance PC as well.
There are four ways to connect a local administration terminal:
Direct connection
Modem connection
Asynchronous Data Unit (ADU)
One 7400A data module and one 7400B data module (recommended) or
two 7400A data modules
Local maintenance PCs are always connected directly.
Directly Connecting a Terminal
Figure 28
Figure 29
Definition
Tip (white/blue)
Ring (blue/white)
Minor RTN (return) (yellow/brown)
Minor (brown/yellow)
Major RTN (return) (violet/orange)
Major (orange/violet)
shows typical connections for a local maintenance PC.
shows typical connections for a local administration PC.
Table 16.
