4 Data Modules and Asynchronous Data Units
Connect Data Modules
25. Press the NEXT/NO button until the RI = correctValue ? or RI -
> correctValue ? prompt appears. Then press the ENTER/YES button.
26. When the CONTINUE? prompt appears, press the ENTER/YES button.
27. When the SET RL LEAD? prompt appears, press the NEXT/NO button to
skip this setting.
28. When the SET SIGLS DISC? prompt appears, press the ENTER/YES
button.
29. Press the NEXT/NO button until the SIGLS DISC = correctValue ? or
SIGLS DISC -> correctValue ? prompt appears. Then press the ENTER/
YES button.
30. When the CONTINUE? prompt appears, press the ENTER/YES button.
SET RI = ON?
Push the button indicated by the arrow ( )
SET RL LEAD?
Push the button indicated by the arrow ( )
SET SIGLS DISC?
Push the button indicated by the arrow ( )
SIGLS DISC = ON?
Push the button indicated by the arrow ( )
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
