Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 63

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
4 Data Modules and Asynchronous Data Units
Connect Data Modules
Setting speed options on 7400A DCE
1. Press the NEXT/NO button to continue with the setup procedure.
2. The SET OPTIONS? prompt appears on the LCD. Press the ENTER/YES
button.
A series of SET number SPEED? prompts appears.
3. Press the NEXT/NO button until you see the SET 9600 SPEED? prompt.
Then press the ENTER/YES button.
Most DEFINITY connections operate at the 9600 speed.
4. The 9600 = ON? prompt appears. Press the ENTER/YES button.
5. The CONTINUE? prompt appears. Press the ENTER/YES button.
0 0 — 0 0
Push the button indicated by the arrow ( )
SET OPTIONS?
Push the button indicated by the arrow ( )
SET 9600 SPEED?
Push the button indicated by the arrow ( )
9600=ON?
Push the button indicated by the arrow ( )
CONTINUE?
Push the button indicated by the arrow ( )
0 — —
DATA
DATA
DATA
DATA
DATA
April 2000
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
Issue 1
41
