4 Data Modules and Asynchronous Data Units
Connect Data Modules
3. The VIEW OPTIONS? prompt appears. Press the NEXT/NO button.
Setting speed options for the 7400D
The data speed depends on the exact application, but most require 9600 bps or,
less commonly, 19200.
1. Press the NEXT/NO button to continue with the setup procedure.
2. The SET OPTIONS? prompt appears on the LCD. Press the ENTER/YES
button.
A series of SET number SPEED? prompts appears.
3. Press the NEXT/NO button until you see the SET yourSpeed SPEED?
prompt. Then press the ENTER/YES button.
VIEW OPTIONS?
Push the button indicated by the arrow ( )
0 0 — 0 0
Push the button indicated by the arrow ( )
SET OPTIONS?
Push the button indicated by the arrow ( )
SET yourSpeed SPEED?
Push the button indicated by the arrow ( )
DATA
0 — —
DATA
DATA
DATA
April 2000
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
