11 Stratum 3 Clock
Set Clock Options
Table 21. Y-Cable Clock-End Cross-Connects for Reliability
From Stratum 3 Clock
Lead Lead Color/
Name Terminal
RREF1 W-BL/1
TREF1 BL-W/2
RREF2 W-O/3
TREF2 O-W/4
Table 22. TN780-Carrier Cross-Connects for Standard Reliability
From Stratum 3 Clock
Lead Lead Color/
Name Terminal
BCLKRTN R-O/13
BCLKLST O-R/14
BPWRRTN R-BR/17
BPWRLST BR-R/18
REF2RTN W-BR/7
REF2LST BR-W/8
SCLKRTN R-BL/11
SCLKLST BL-R/12
SPWRRTN R-G/15
SPWRLST G-R/17
BCLKRTN R-O/13
REF1RTN W-G/5
REF1LST G-W/7
CCA01R R-S/19
To Y-cable clock end
(primary)
Lead Lead Color/
Name Terminal
V-O/43
O-V/44
To TN780 carrier A
Lead Lead Color/
Name Terminal
ALRM5B V-G/45
ALRM5A G-V/47
ALRM4B BK-BL/21
ALRM4A BL-BK/22
ALRM3B R-BR/17
ALRM3A BR-R/18
ALRM2B R-BL/11
ALRM2A BL-R/12
ALRM1B Y-BL/31
ALRM1A BL-Y/32
ALRM5B V-G/45
ALRM0B W-BR/7
ALRM0A BR-W/8
EXTSYN0T V-BL/41
April 2000
To Y-cable clock end
(secondary)
Lead Lead Color/
Name Terminal
V-O/43
O-V/44
To TN780 carrier B
Lead Lead Color/
Name Terminal
Continued on next page
