Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 163

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
11 Stratum 3 Clock
Set Clock Options
Table 24. Circuit-Pack Cross-Connects for High or Critical Reliability
From Stratum 3 Clock
Lead Lead Color/
Name Terminal
SCLKRTN R-BL/11
SCLKLST BL-R/12
SPWRRTN R-G/15
SPWRLST G-R/17
REF1RTN W-G/5
REF1LST G-W/7
CCA01R R-S/19
CCA01T S-R/20
CCB01R BK-BL/21
CCB01T BL-BK/22
CCA02R BK-O/23
CCA02T O-BK/24
CCB02R BK-G/25
CCB02T G-BK/26
7. Bridge the jumper wires to cross-connect from the TN780 in A and B
carriers to the Stratum 3 Clock.
8. Dress the cables down sides of the cabinet and run through the cable
Slack Manager, if provided.
9. Administer the switch for the clock .
To TN780 carrier A
Lead Lead Color/
Name Terminal
ALRM2B R-BL/11
ALRM2A BL-R/12
ALRM1B Y-BL/31
ALRM1A BL-Y/32
ALRM0B W-BR/7
ALRM0A BR-W/8
EXTSYN0T V-BL/41
EXTSYN0R BL-V/42
EXTSYN1T Y-G/35
EXTSYN1R G-Y/37
To TN780 carrier B
Lead Lead Color/
Name Terminal
ALRM2B R-BL/11
ALRM2A BL-R/12
ALRM1B Y-BL/31
ALRM1A BL-Y/32
ALRM0B W-BR/7
ALRM0A BR-W/8
EXTSYN0T V-BL/41
EXTSYN0R BL-V/42
EXTSYN1T Y-G/35
EXTSYN1R G-Y/37
Continued on next page
Issue 1
April 2000
141
