10 ISDN Converters and Adapters

Converters for Multicarrier Cabinets

1. To TN464F DS1 circuit pack and
PRI-to-BRI converter circuit pack
2. DEFINITY administration PC
3. RS-232 cable to front of converter
circuit pack
4. 888B coaxial converter
5. Coaxial connection to 2-Mbps
facility
Figure 40. Typical PRI to BRI Converter Cabling
NOTE:
The inset shows details of the cable connections between the circuit packs.
Connect the DEFINITY administration PC to the RS-232 connector on the
front of the PRI converter circuit pack.
Converters for Multicarrier Cabinets
PRI to DASS and PRI to DPNSS Converters
1. Connect the DEFINITY administration PC to the RS-232 connector on the
front of the PRI converter circuit pack.
Figure 41
converter or the CCSC-2 PRI-to-DPNSS converters to the coaxial facility.
0007_0 RBP 051396
shows typical connections from the CCSC-1 PRI-to-DASS
8
(2B+D)
1
(2B+D)
6. Coaxial cable from PRI converter
circuit pack to coaxial converter
7. TN464F circuit pack
8. PRI-to-BRI converter circuit pack
9. Jumper coaxial cable
10. Inset showing connections on rear of
carrier
Issue 1
April 2000
131
7
(2B+D)
