Printers

Configuring the AT&T Model 572
Printers
This chapter provides information on configuring the various printers supported
by Lucent.
Configuring the AT&T Model 572
An AT&T Model 572 printer functions as a CDR device, system printer, or journal
printer. The options are set with function keys rather than DIP switches.
shows the arrangement of the function keys on the printer control panel.
1
Power
1. Power on button
2. Alarm button
3. Print quality button
Figure 21. Control Panel for 572 Printer
2 3
Alarm Print
On Quality
4 5
On Line
Line Feed
4. On line button
5. Line feed button
6. Form feed button
Issue 1
April 2000
91
6
Figure 21
6
Form
Feed
