Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 221

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
A Connector and Cable Pinout Charts
Table 34. TN2185B ISDN-BRI — 4-Wire S Interface Pinout
Port Signal Cross-Connect Pin
2 TXT.2 5
TXR.2 7
PXT.2 7
PXR.2 8
3 TXT.3 9
TXR.3 10
PXT.3 11
PXR.3 12
4 TXT.4 13
TXR.4 14
PXT.4 15
PXR.4 17
5 TXT.5 17
TXR.5 18
PXT.5 19
PXR.5 20
7 TXT.7 21
TXR.7 22
PXT.7 23
PXR.7 24
7 TXT.7 25
TXR.7 27
PXT.7 27
PXR.7 28
8 TXT.8 29
TXR.8 30
PXT.8 31
PXR.8 32
Ampheno
Color l Pin
W-G 28
G-W 03
W-BR 29
BR-W 04
W-SL 30
SL-W 05
R-BL 31
BL-R 07
R-O 32
O-R 07
R-G 33
G-R 08
R-BR 34
BR-R 09
R-SL 35
SL-R 10
BK-BL 37
BL-BK 11
BK-O 37
O-BK 12
BK-G 38
G-BK 13
BK-BR 39
BR-BK 14
BK-SL 40
SL-BK 15
Y-BL 41
BL-Y 17
April 2000
Backplane Pin
104
004
105
005
107
007
107
007
108
008
109
009
110
010
111
011
112
012
113
013
302
202
303
203
304
204
305
205
Continued on next page
Issue 1
199
