Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 87

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
4 Data Modules and Asynchronous Data Units
Connect Data Modules
1. When the SET CI LEAD? prompt appears, press the ENTER/YES button.
2. Press the NEXT/NO button until you see the CI = correctSetting ? or
correctSetting ? prompt. Then press the ENTER/YES button.
3. When the CONTINUE? prompt appears, press the ENTER/YES button.
4. When the SET CH LEAD? prompt appears, press the ENTER/YES
button.
5. Press the NEXT/NO button until you see the CH = correctSetting ? or CH -
> correctSetting ? prompt. Then press the ENTER/YES button.
6. When the CONTINUE? prompt appears, press the ENTER/YES button.
SET CI LEAD?
Push the button indicated by the arrow ( )
CI = correctSetting ?
Push the button indicated by the arrow ( )
CONTINUE?
Push the button indicated by the arrow ( )
SET CH LEAD?
Push the button indicated by the arrow ( )
CH = correctSetting ?
Push the button indicated by the arrow ( )
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
DATA
DATA NEXT/NO BACK ENTER/YES
DATA NEXT/NO BACK ENTER/YES
Issue 1
April 2000
65
CI ->
