Lucent Technologies DEFINITY Installation For Adjuncts And Peripherals page 219

DEFINITY ECS Release 8.2
Installation for Adjuncts and Peripherals 555-233-116
A Connector and Cable Pinout Charts
Table 31. Lead and Color Designations
Cross-Connect Pin
47
47
48
49
50
Table 32. DS1 Interface cable H600-348
50-Pin
Pin Color
38 W-BL
13 BL-W
39 W-O
14 O-W
41 W-G
17 G-W
42 W-BR
17 BR-W
44 W-SL
19 SL-W
45 R-BL
20 BL-R
47 R-O
Amphenol
Color Pin
G-V 23
V-BR 49
BR-V 24
V-SL 50
SL-V 25
15-Pin
Designation Pin
Plug 04
LI (High) 11
LI 03
LO 09
LO (High) 01
Plug 03
LI (High) 11
LI 03
LO 09
LO (High) 01
Plug 02
LI (High) 11
LI 03
LO 09
LO (High) 01
Plug 01
LI (High) 11
Backplane Pin
212
313
213
300
200
Continued on next page
Color Designation
W-BL LI (High)
BL-W LI
W-O LO
O-W LO (High)
W-G LI (High)
G-W LI
W-BR LO
BR-W LO (High)
W-SL LI (High)
SL-W LI
R-BL LO
BL-R LO (High)
R-O LI (High)
Continued on next page
Issue 1
April 2000
197
