4 Data Modules and Asynchronous Data Units
Connect Data Modules
10. The maintenance-option EIA leads configure loopback testing for the data
module. You do not need to set any specific options. So, when the SET LL
LEAD? prompt appears, press the NEXT/NO and BACK buttons together
to return
11. When the SAVE CHANGES? prompt appears, press the ENTER/YES
button.
The CHANGES SAVED message flashes on screen, and you return to the
HOME screen. The data module is now configured.
Restoring factory defaults on 7400A DTE
If necessary, you can always revert to the factory default settings. From the
HOME screen, proceed as follows.
1. To access the menus, press the NEXT/NO button.
2. When the SET OPTIONS? prompt appears on the LCD, press the NEXT/
NO button.
HOME.
SET LL LEAD?
Push the button indicated by the arrow ( )
SAVE CHANGES?
Push the button indicated by the arrow ( )
0 0 — 0 0
Push the button indicated by the arrow ( )
SET OPTIONS?
Push the button indicated by the arrow ( )
DATA
DATA
0 — —
DATA
DATA
April 2000
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
NEXT/NO BACK ENTER/YES
